Silicone Oil Filling Machine For Pen Refill

Silicone Oil Filling Machine For Pen Refill

TRANSOCEAN® silicone oil filling machines for pen refills are specially designed for automatic quantitative filling of silicone oil for pen refills after ink filling process. It consist of the refill silo, refill distribution & conveying unit, refill detector, silicone oil filling unit, finished refill collector and control cabinet.

Content

Introduction

●TRANSOCEAN® silicone oil filling machines for pen refills are specially designed for automatic quantitative filling of silicone oil for pen refills after ink filling process. It consist of the refill silo, refill distribution & conveying unit, refill detector, silicone oil filling unit, finished refill collector and control cabinet.

Control panel
Pressure vessel for silicone oil



Flow chart

●Refill distribution→transfer by chain type conveyor→refill detecting→silicone filling→collection



Main technical specifications

●Refill silo capacity: about 2,000 PCS

●Processing capacity: 4PCS refills/ batch, 180~200PCS/ min

●Drive of silicone in the filling nozzles: By compressed air

●Silicone oil tank: atmospheric pressure type oil tank or pressure vessel for silicone oil

●Air pressure in silicone oil tank (if any): 2bar

●Storage capacity: about 1,000PCS

●Air source pressure: 6bar

●Installed power:about 3.5kW

●Outline dimension: 1590mm*870mm*1720mm

●N.W.: 650KGS



Main compositions

●Pneumatic components: SMC

●PLC: OMRON

●Packing material: heat-treated wooden case



Advantages
1. Efficiency: The automatic filling process ensures high-speed continuous operation and minimizes human intervention.
2. Precision: Ensures that each refill is filled with the right amount of silicone oil, ensuring consistent product quality.
3. Customization: The machine can be adjusted according to different types of refills, filling volumes, and silicone oil viscosities, allowing it to meet a variety of production needs.
4. Reduced waste: By precisely dispensing the right amount of silicone oil, these machines help minimize material waste and improve cost-effectiveness.

Packing processes
Container load
