TRANSOCEAN® Jumbo bags for asphalt are specially designed for packing of high temperature materials such as raw asphalt, oxidized asphalt, modified asphalt and paraffin.TRANSOCEAN® asphalt Filling machine and asphalt melting equipment are available as an option.
Introduction:
●TRANSOCEAN® Jumbo bags for asphalt are specially designed for packing of high temperature materials such as raw asphalt, oxidized asphalt, modified asphalt and paraffin.
Technical specifications:
|
Description |
Standard Size L*W (mm) |
Max. T. ℃ |
Filling T. ℃ |
Melting point ℃ | |
|
Series TA Jumbo bag |
500kg |
Inner: 1900*1550 Outer: Top:650*650 Bottom: 750*750 Height: 900mm (+/-30mm) |
110 |
≤105 |
Inner liner film totally melted at 150-155, outer woven not meltable |
| 1000kg |
Inner: 2900*2050 Outer: 800*800 Bottom: 1000*1000 Height: 1000 (+/-40mm) |
||||
|
Series TB Jumbo bag |
500/ 1000kg |
See TA |
120 |
≤115 |
Inner film lining 60%-80% melt at 165-170, outer Non-meltable woven |
Remarks:
●OEM is available.
●Filling machine and melting equipment are available as an option.
Features:
●Withstand high temperature up to 105~170℃
●All film linings and outer woven can be melted thoroughly into bitumen/asphalt at the specific temperature. Free of pollution to the asphalt.
●Stacking limit: 10-15 layers
●Excellent UV resistance, stand with sunshine for more than 5 months.
